Balizas de señalización patrones de luz

Rotary Switch wiring CH1 CN2 CH1 CN2 CH1 CN2 CH1 CN2
OFF OFF ON OFF OFF ON ON ON
0 Apagada Giro (120 rpm) Destello triple Dimmed Giro (120 rpm)
1 Apagada Giro (180 rpm) Destello triple Dimmed Giro (180 rpm)
2 Apagada Destello triple Patrón de pulsos Dimmed Destello triple
3 Apagada Giro (60 rpm) Giro (120 rpm) Giro (180 rpm)
4 Apagada Dimmed Destello simple Half-side emitted Destello doble Dimmed Half-side emitted Destello triple
5 Destello triple Dimmed Destello triple Half-side emitted Destello triple Dimmed Half-side emitted Destello triple
6 Patrón de pulsos Dimmed Patrón de pulsos Half-side emitted Patrón de pulsos Dimmed Half-side emitted Patrón de pulsos
7 Giro (60 rpm) Dimmed Giro (60 rpm) Half-side emitted Giro (60 rpm) Dimmed Half-side emitted Giro (60 rpm)
8 Giro (120 rpm) Dimmed Giro (120 rpm) Half-side emitted Giro (120 rpm) Giro (120 rpm)
9 Giro (180 rpm) Dimmed Giro (180 rpm) Half-side emitted Giro (180 rpm) Giro (180 rpm)
